Softline 78 Pine Windows fixed

Features;

1. Our windows are available in two types of timber: pine, meranti 450

2. High quality achieved through application of first class components.

3. Focus on ecology thanks to the application of natural wood and special water-based stains and varnishes

4. Long lasting woodwork thanks to the aluminium threshold that protects the wood against UV rays and water  from the glass with thermos-drip that facilitates water drainage

5. The option of a wide range of colour choices

6. High level of energy efficiency provided by the optimum quality of materials used for production, special sealing system and the proper glass packages We supply hard and medium soft woods that have been Resin dipped for maximum durability and protection,

Colour range

Wide range of colours paints stains are available.

Glass  options available

Double glazed 24mm sealed units  with thermal transmittance coefficient U value =1,0 W/(m2K)  to PN-EN674 standard. The possibility to apply Double -, Triple- or Quad -glazing •as an option

For Softline 68 mm – max. sealed unit thickness  is 32 mm with thermal transmittance coefficient U value  = 0,8 W/(m2K).

For Softline 78 mm – max. Sealed unit is 44 mm with thermal transmittance coefficient of U value  = 0,6 W/(m2K). •

For Softline 88 mm – max. Sealed unit is 54 mm with thermal transmittance coefficient of with triple glazed is U value = 0,5 W/(m2K) or U = 0,3 W/(m2K) with Quad with krypton. The possibility to apply glass with enhanced sound insulation, toughened , safety, anti-burglary, ornament, solar protective as options are available.

You will need a price on application for this  88mm profile.

Fittings.

Maco Multi Matic KS hardware with two anti-burglary bolts fitted as standard. Window equipped anti jemmi option for  handle misplacement and a sash lift *; micro-ventilation slot **; optionally application of concealed hinges *Depending on the window height **for tilt and turn windows

Profile options.

We have options for 3 depths: 68 mm, 78 mm, 88 mm in three types of timber three- or four-layer solid square timber: meranti 450+, pine or larch.

Spacer Bar

Steel galvanized frame as standard. Optionally Swisspacer Ultimate available in various colour options.

For Softline 78mm and 88mm system an extra internal seal is included giving enhanced thermal insulation U value = 0,80 W/(m2K)* *coefficient calculated with 4/18/4/18/4-0,5w/(m2K) triple glazed for reference window softline 88mm.
