Our Krispol fully Insulated 40mm and 60mm insulated garage doors either with manual or automatic and even smart operation with wide range of colours and finishes, we offer an unrivaled product.
Variants
Variant 1
Our Krispol sectional doors are manufactured in 2 variants the first option here is a 40mm thick insulated panel that is sealed along the whole perimeter and between the sections. The shape of the upper arc was designed specifically to optimally press the upper panel of the door to the lintel giving a better close. This design specification gives our doors one of the best thermal insulation energy saving specifications on the market at this range of doors at : U= 1,12 [W/m2K]
Variant 2
This option is specifically for energy-efficient houses/buildings our VENTE K2 RFS 60 door with the thickness of 60 mm. This exceptionally warm door has also double sealing of the lower panel, sealing between the sections and additional sealing along the perimeter which reduces thermal bridges between the wall and the angles, this gives a superb energy efficient heat loss coefficient of U=0,9 [W/m2K] this works well with integral garage systems where rooms above them may suffer cold spots.
Variant 3 Rolling doors
Rolling door is a constructional solution allowing for the installation of the door in a garage where you want to obtain a maximum free space directly under the ceiling, or you have limited internal space where there are untypical garages and utility rooms.
The door is opened up vertically, and the roller package is hidden in the box located outside in the (RGZ) or inside if with (RGW) the garage above the entrance.
New Warm insulation systems
The revolutionary K2RS garage door warm installation system is already available at our points of sales.
For the end user it means a significant improvement to the heat transmission factor. This innovative solution submitted to the patent office by KRISPOL is based on providing distance between the vertical angle bracket and the lintel strip with the shaft supports from the wall. The spacer is prepared for mounting to the vertical angle bracket; it has a socket for an additional gasket. Two gaskets better seal the connection. The EPS hard foam used for assembly allows the insulation to be improved by around 30%, which in practice gives up to 20% better thermal insulation for the entire garage door.
Safety Features
- We constantly improve our products by implementing solutions which improve safety of use and protect the functions of the running gears and mechanisms. additional protection is installed to every door in order to protect it from falling down if a spring snaps or breaks.
- An overload switch is a standard feature on the drives on all of our doors ensuring safety at all times, this lifts the door approximately 10cm if an obstacle is found. An automatic door can also be equipped with sensors preventing the door from closing if there is an obstacle in the door clearance. Driving rollers installed in all doors can be additionally equipped with finger trap protection. The sections of the doors were also designed to have a safe shape no pinching, making our doors the safest most efficient on the market, you only want to do this once it pays to get it right first time, ‘’install the best with MrGB’’.
Insulation
The garage door with a 40mm panel, which normally obtains a heat loss value U=1.09 [W / m2K], reaches parameters similar to doors with a 60 mm panel with our warm installation system, U value at U = 0.89 [W/m2K]. On the other hand, the door with a 60 mm panel using a warm installation system is currently the warmest solution designed for built-in garages and allows to achieve u value at U = 0.77 [W/m2K] (calculations based on a 5000×2250 mm door)
Our Krispol Garage door systems are reliable quiet and easy to operate with enhanced automatics. The mechanisms used in our products are tried tested and highly specified. We guarantee an easy and unproblematic use but also give the possibility to connect our door systems to any ‘intelligent home’ system and alarm installations no problem making our doors stand out from what is in the market today.
Running Gear
Krispol garage doors have bearing rollers in all our sectional doors this also helps minimise the number of connections on the rail guides. The rollers used are manufactured with a PVC inserts this eliminates vibration and allows for quiet smooth door operation. A significant point with our doors is no matter what the size ie width of the door is, each door manufactured by our company can be easily opened with one hand with smooth action due to the use of twin torsion springs system which provide an optimal balance of the door. You only want to install you garage doors once. So install the best with MRGB.
Solid Construction
No matter how good the door looks from the outside, it cannot be forgotten that the door should have a solid construction in the first place. Therefore, it is worth checking what the door looks like from the inside.
The mechanisms of our doors include solutions which reinforce the construction of the doors, facilitate assembly and fit the garage space, they are also reliable and provide an aesthetic look from inside.
Our doors are for everyday use
We constantly improve our products by implementing solutions which improve safety of use and protect the functions of mechanisms. Additional protection is installed in every door to protect it from falling down if a spring bursts.
An overload switch is a standard feature of the drives, it lifts the door of approximately 10 cm if an obstacle is found. An automatic door can also be equipped with photocells preventing the door from closing if there is an obstacle in the door clearance. Driving rollers installed in all doors can be additionally equipped with finger protection. The sections of the doors are also designed to have a safe shape,
For more information on our doors and prices please contact us now.
We are UK Number 1 trade partner and authorized dealer of Krispol Doors.
