System structures may be used both in commercial and residential applications.
Great thermal insulation parameters thanks to the application of special insulating inserts in MB 70HI system.
Resistant structure thanks to the high-quality aluminium profile.
Wide possibilities to customise the interior and exterior resulting from great selection of colours.
The possibility to build durable and solid large-size structures.
The usage comfort and functionality are ensured by the high-quality profiles and modern fittings that improve the smooth system operation.
Profile:
Our Profiles have a three-chamber system with an overall frame depth of 70 mm (frame), 79 mm (sash) with a polyamide thermal break reinforced with composite plus thermal inserts that insulate inside of the section and the space between window panes within the MB-70Hi system.
Glazing:
Our sealed units for this profile are up to 50 mm thick. Double glazed with thermal transmittance U Value of = 1,0 W/(m2K) according to PN-EN674. The possibility to have triple glazed with a U Value of 0,5 W/(m2K) coefficient with enhanced sound and insulating, tempered, safety, anti-burglary, ornament, solar protective glass is also possible,
Spacer frame .
Aluminium spacer bar or optional swiss spacer or swiss ultimate are available in various colours.
Locking systems
MACO MULTI MATIC KS Locking systems with Multipoint and dual opening positions all fittings-as standard.
Threshold:
Reinforced multi chambered UPVC threshold with thermal break for minimum heat loss.
