Iglo 5 Classic Door TT door no post side panel with midrails
Excellent quality at affordable prices
5-chamber 70mm profile Virgin grade upvc
Double draught sealed with EPDM and Q lon;
Colour range this profile is available in 45 Renolit foil grain colours on white or brown core profile
double / triple glazed available
IGLO 5 Doors combine exceptional looks with the most advanced technologies in the field of thermal insulation. The sophisticated design is produced using the latest process technology, with the rounded edges reflecting the latest trend on the window market. The thermally insulated 5-chamber system offers high insulation values that ensure minimal heating costs in winter and less power consumption when operating air conditioning systems in the summer. Security also plays a central role for us. The high-quality branded MACO MULTI MATIC KS fittings are used in all Profiles. Together with the 5-chamber profile and full steel reinforcement, IGLO 5 Classic windows are a worthwhile investment in durable and long-lasting windows.
Features and Benefits
Energy efficiency as a result of the optimal profile structure, specially designed sealing system made of foamed EPDM and glass packages with low thermal transmittance.
High security level guaranteed by two anti-burglary bolts as standard.
Wide range of oil colours finish
Excellent thermal parameters that ensure heat saving as a result of optimal structure and the EPDM sealing.
Excellent in sound insulation
Double / triple glazed options
sealed units with Acoustic -security and solar protection available,
Glazing Options
Glazing thickness up to 40 mm. Double glazed package with thermal transmittance coefficient Ug =1,0 W/(m2K) according to PN-EN674 as standard. The possibility to apply a unit of Ug = 0,6 W/(m2K) coefficient. The possibility to apply glass with enhanced sound insulation, tempered, safety, anti-burglary, ornament, solar protective. Sound insulation Rw = 34-44 dB depending on applied glass packages the possibility to apply swiss spacer Ultimate as standard
Maximum transparency in terms of costs and glass
The right glazing is an essential part of optimal thermal insulation. Thanks to a special Thermofloat, our modern SGG PLANTITHERM ®XN insulating glass has extremely low U values 1.1 W / m²K in our standard double glazing solution,This saves you noticeably valuable energy. Triple glazing and the so-called "warm edge spacer" are also available for improved energy efficiency. This composite spacer bar has a reduced thermal conductivity in contrast to the conventional aluminium edge. An extensive selection of ornamental and structured glass as well as suitable safety glass fulfil individual needs -
Windows and doors offer a large target area for burglars. Sufficient burglary protection is therefore essential to adequately protect your home. The MACO Multi MATIC KS fittings installed to our profiles meet and are compliant to PAS 24 certification
Technical cross-sections and detailed drawings
Precise planning is the cornerstone of every building project. Only in this way can all elements be coordinated with one another and the individual work steps carried out sensibly. Various cross-sections, CAD plans and detailed views are available for the IGLO 5 classic UPVC profile from MRGB Glass solutions, to plan your windows with millimetre precision.
Roller shutters, window sills, handles and more - our window accessories
Top-mounted or front-mounted roller shutters are available with this profile along with insect screens at additional cost , please contact us for more information.
