Reinforcement with aluminium profiles with thermal inserts
EPDM and brush seal
PAS 24
Leaf depth: 82 mm, frame depth: 194 mm
Maximum glass thickness up to 49mm
Sash weight: up to 400 kg
Fully Reinforced threshold
43 Foil finishes.
Features
This configuration with fully reinforced upvc profile is available up to 6.5m wide and 2.6m high.in a twin track system.
Profile:
The multi-chamber system promises optimal thermal insulation and thus a healthy room climate. In conjunction with selected low-emission coated glazing options from double to triple glazed and an innovative sealing system, giving an outstanding thermal insulation parameters are achieved.
Glazing:
Maximum glazing thickness up to 49 mm. with double triple are available Optional use of special glasses such as laminated safety glass or ESG as well as solar protection glass or sound reducing glass available upon request.
Fittings:
Lift & slide hardware system with a sash weight of up to 400 kg. Safety locking bolt features and locking device for the night vent.
Automation:
The IG HS series is available in Automatic - Remote control operation or manual - please contact for further information .
Threshold:
Reinforced multi chambered Upvc threshold with thermal break for minimum heat loss
Features and benefits of our IG5 HS lift & slide door - Innovative in design with stunning performance
Large panoramic windows want to be used optimally! The optimal solution for large openings is our IG5 HS and slide door aluminium patio door sliding system, The IG5 HS profile is suitable for large structures with a width of up to 6.5 m in a twin set of doors and up to 13m in a four configuration and remains very stable and comparatively light. Depending on the configuration, two to three running track within the frame ensure easy use of the elements and maximum functionality even with a doors leaf weighing up to 400 kg.
We can offer a wide range of sealed unit options double and triple glazed as standard options the IG5 HS door achieves superb heat and sound insulation parameters. In addition, the insulating EPDM seals ensure 0% air and water tightness.
We can offer over 43 foil colours and wood grain finishes and even textured options are available to meet all design requirement. The space-saving opening mechanism of the IG5 HS door also enables completely free interior design, as no opening radius of the patio door must be considered. Convenient operation is provided by suitable fittings with manual or automatic locking available. all doors are PAS 24 compliant for maximum security as standard.
For price and more information please contact us now.
