MB77 Bifold doors
Features of our Bi folding Aluminium doors.
- 3-chamber profile made of aluminium
- Frame installation depth of 77 mm
- Folding sliding door fitting system
- Double, triple or quadruple glazing available.
- Robust, durable and easily maintained
- Optionally with Obscure, clear Low e or solar glass applications.
Profile:
A 3-chamber profiles made of high-quality aluminium with a frame construction depth of 77 mm.
Glazing:
Maximum glazing thickness up to 50 mm. Individual insulating glazing with double triple and quadruple glazing available with warm edges spacer for outstanding U values between 0.5 Kw/m2 quad up to 0.7KW/m2 triple and 1.0Kw.ms double glazed options /standard is triple glazed with the option of quad, with ornamental /obscure glass, solar and low e glass with swiss spacer , filled with argon or krypton for maximum performance.
Fittings:
All-round high-quality MACO fittings, stainless steel running gear top and bottom for maximum durability and performance.
Threshold:
Aluminium threshold with thermal break for minimum heat loss come in various options from low -medium and standard ranges all are weather rated.
About our MB77 Bi Folding system,
- Our aluminium Bi folding door system MB-77 is the ideal solution for large open glazed areas. The aluminium profile is light, but still extremely stable and therefore ideally suited for wide glazing. The running rails are attached either to the upper frame (top-hung) or to the threshold (bottom-hung). The folding sliding door simply slides along them - after the door leaf has been operated - and opens inwards or outwards
The 3-chamber profile achieves excellent thermal insulation U values. In addition, the profile is triple EPDM draught sealed for maximum efficiency An extensive range of 200 RAL colours .
For more information please contact us direct.
