Commercial Garage Door Grille Systems
Product Description
Our Krispol Rolling grilles perform different functions at the same time. They are produced in many versions, depending on their protection class against burglary, air transmission,drive types and available designs and colours.
Similarly to rolling doors, the main advantage of the grilles is their construction allowing the use of the building’s floor space on both sides of the facility and under the ceiling.
Steel and Aluminium
We offer aluminium and steel grilles. Steel grilles are heavy and have very durable mechanisms. They are perfect to protect the entrance to the car parks, warehouses etc. aluminium grilles are lighter in constructions, aimed mostly for sales outlets in shopping centres, jewellers’ and restaurants for examples in some cases are perfect for residential areas.
The design and construction of the roller grilles depends on the places where they are to be installed and their functions. The grilles with brick structures are good for rooms that have to be both safe and open. Aluminium grilles with rectangular openings are perfect for modern interiors where there is a need of high ventilation. Grilles made of steel and aluminium perforated profiles provide the optical aperture and air permeability at the level of 28%. Grilles made of steel and aluminium perforated profiles can be painted with one of the 200 RAL colours.
Colour options
Grilles made of steel and aluminium perforated profiles can be painted with one of the 200 RAL colours.
Variant Steel R2 SS (G/P)
The shells of R2 SSG and R2 SSP grilles are made of steel pipes, of sinusoidal profiling and clamp-hinge joined.
Grilles are available with two types of drives: with a spring system (R2 SSG) and with electric side drive (R2 SSP).
Safety and reliability.
Rolling grilles are equipped with protection against falling if a spring snaps, the protection is integrated in the drive in the form of emergency brake. All solutions can be extended by additional protection – signal lamps, useful in large industrial facilities or photocells, the grilles will be automatically lifted if there is an obstacle in the clearance area. Sensing edges work similarly as they stop and lift the grilles after encountering an obstacle.
The grilles are optionally manufactured in two safety classes Anti- burglary: RC (EN 1627:2011). A latch lock installed in the bottom panel of the shell serves as protection against burglary, as it is impossible to open the bolted grilles from outside. The access inside the facilities, which require special security, is additionally protected with the access card or coded keypad. The release of a signal to steer the device can be enciphered by as many as 9-digit code. In case of rolling grilles, attention must be paid while lifting the grilles. Protection against coiling on the roll detects the elements which could derail are on the shell while opening and thus stops the grille from operation as a failsafe to protect the system.
Drives.
Automatic grilles is not only about comfort. Functional, modern drives also guarantee safety use and protect the mechanisms of the door. Depending on the intended use, parameters, weight and facility conditions, rolling grilles can be driven with one of the three types of electrical drives.
1. Side, three-phase, fixed drive is used due to its parameters and sizes for intensively used products of large surfaces.
2.Lateral tubular single-phase drive – due to its design – does not require large installation areas.
3.Single phase central drive is used in smaller products
You only want to do this once it pays to get it right first time, ‘’install the best with MrGB’’.
For more information on our doors and prices please contact us now.
We are Number 1 trade partner and authorized UK dealer of Krispol Doors
